Features
- The working face is machined from a single block of mild steel, wherein the poles are demarcated by making slots in the Top surface obviating the need to use filler material.
- 100% safety to Original Machine Bed.
- Universal Clamping directly on Magnetic Chuck.
- 100% Leak Proof.
- Very Rigid and Robust construction.
- No Epoxy * No Expansion * No Deformation.
- No Damage * No Burning.
|
Applications
- Can be used for heavy duty milling operations.
- Tee Slots in the working face of the chuck enables clamping Magnetically and/ or Mechanically all types of jobs be it ferrous or non-ferrous.
- Universal Clamping directly on Electro Permanent Magnetic Chuck.
- Patent Applied.
- 2 in 1 Chuck - Magnetic & Mechanical Clamping.
| |
Available EPM Chuck |
MAGNASLOT |
| Clamping of Ferrous Jobs |
Can be Clamped magnetically. |
Can be Clamped magnetically. |
| Clamping of Non-Ferrous Jobs |
Can only be clamped using special fixtures or vices. |
Can be clamped on T Slots of MAGNASLOT. |
| Working Face Accuracy |
Due to excessive heat generation in some operations, Epoxy bulges. |
Solid Steel Top helps distribution of heat all over MAGNASLOT and retails accuracy. |
- A Complete Magnetic Bed for your Machine.
- The operating voltage is 440 V AC for all chucks.
- Can be designed for other operating voltages.
- The Magnet can be designed for 220/380/400/480 VAC, 50/60 Hz.
- Custom designed solutions also available.
|
|
